This is a quick peek inside Burp AI. I'll show how to proxy its requests, what actually happens when you trigger a feature. This knowledge allows us to redirect Burp AI to your own AI instance. As far as I know, this is not publicly documented.

I covered a shorter version in my DEF CON 33 Bug Bounty Village talk The Year of the Bounty Desktop: Bugs from Binaries. See the extended slides (pages 14–22) (placeholder for video).

Quick Start

Run two Burp instances.
In the first (Burp client), set the upstream proxy to localhost:9000.
In the second (Burp server), create a listener on port 9000.
Add the Burp CA to the JRE cacerts.
Use AI in Burp client; watch results in Burp server.

Quick Facts

AI is off by default (props to PortSwigger).
All AI traffic goes to ai.portswigger.net. Block it to disable Burp AI.
This is also mentioned in the documentation, but I wanted to confirm.
Requests/responses are JSON.
Burp had "agentic behavior" pre‑hype. E.g., AI can ask Repeater or the login recorder to act.

Motivation

I wanted to see how Burp AI works internally: where traffic goes and what is sent. A big Burp AI flaw (to me) is the lack of a configurable endpoint. I trust PortSwigger; I'm running their software. Still, I can't send internal data to an outside service.

Proxying Burp

I'll walk through what I tried. What worked, what didn't, and what I'd have tried next.

Checking the Logs

Burp has a built-in Logger, so I started there. Only some Burp AI requests show up there. When I clicked Explore Issue for "Exploring Strict transport security not enforced on example.net" I saw only one AI request.

Here's how the issue looks in Burp after exploration:

Exploring HSTS in example.net

And this is the only request Logger captured:

Only request captured in Logger

I've not investigated this, but Logger likely uses the same APIs extensions use, so an extension won't see everything either. Those APIs are:

Legacy API: void registerHttpListener(IHttpListener listener)
Montoya API: Registration registerHttpHandler(HttpHandler handler)

Upstream Proxy

Burp supports an upstream proxy, so we can intercept outbound traffic. It's "proxy‑aware" and sends the CONNECT request properly. For background, see my 2016 post Thick Client Proxying - Part 6: How HTTP(s) Proxies Work.

For more about proxying Burp (and other similar tools), read my Thick Client Proxying - Part 4: Burp in Proxy Chains blog.

Run two instances of Burp. Let's call them Burp client and server.
Set the Upstream Proxy for Burp client to localhost:9000.
Create a proxy listener in Burp server on port 9000.

Burp client and server setup

After wiring this up I clicked the purple magic icon (bottom right) to check my Burp balance. Surprisingly, it failed.

Failed Burp balance check

I'd already added Burp's CA to the Windows certificate store. So what broke?

JRE cacerts File

Burp is written in Java. The Windows version bundles a Java Runtime Environment (JRE). The executable wraps java -jar ... plus flags from .vmoptions files.

The JRE has its own certificate trust store at JAVA_HOME/lib/security/cacerts. On Windows it's located at: %LocalAppData%/Programs/BurpSuitePro/jre/lib/security/cacerts.

We can import the Burp CA with keytool. Keytool is conveniently bundled with JRE at JAVA_HOME/bin/keytool.

Extract the Burp CA in DER format.
(Optional) cd into .../jre/lib/security/ for convenience.
Run the following command. Adjust the paths as needed.

..\..\bin\keytool.exe -importcert -alias burp -keystore cacerts
    -storepass changeit -file /path/to/burpca.crt

Done. Now the balance request shows up in Burp server. GET to https://ai.portswigger.net/burp/balance with a base64 token in the Portswigger-Burp-Ai-Token header.

Burp balance check request

Token size is 864 bytes base64 and 648 bytes decoded. High entropy (7.61 Shannon) so likely random/encrypted.

Entropy of the token in CyberChef

What's Inside Burp AI

Burp has quite a few AI features. Let's look at some of them.

Explore Issue

Each issue has an Explore Issue button. Here I use the HSTS finding on example.net.

The 'Explore HSTS' button

First request: POST to https://ai.portswigger.net/ai/hakawai-explore-service/api/v1/start. Values are replaced with {{ }} placeholders, but you can guess them.

POST /ai/hakawai-explore-service/api/v1/start HTTP/2
Host: ai.portswigger.net

{
  "issue_definition": {
    "name": "Strict transport security not enforced",
    "type": "STRICT_TRANSPORT_SECURITY_NOT_ENFORCED",
    "detail": null,
    "background": "{{ description from PortSwigger KB}}",
    "evidence": [
      {
        "type": "REQUEST_RESPONSE",
        "request": "{{ request }}",
        "response": "{{ response }}",
        "request_highlights": [],
        "response_highlights": []
      }
    ]
  }
}

We see:

Finding name and type (same).
Description from the Burp KB (description section of this page) as HTML.
Full originating request and response.

We don't see any prompts. It's injected later by the Burp AI proxy. They are easy to guess.

The response instructs Burp to send a request. It looks like a Repeater action, but nothing appears there. This is the same request we saw in Logger earlier.

'Explore HSTS' response

Response structure:

{
  "exploration_id": "{{ some guid }}",
  "step_title": "Check for security headers and HTTPS redirect",
  "step_action": "I'm sending a basic GET request to examine the server's security headers and see if there's any HTTPS redirect mechanism in place. This will help us understand what security controls are missing and how we might exploit this weakness. Specifically, I'm looking for:\n1. Absence of HSTS header\n2. Lack of automatic HTTPS redirect\n3. Any other security headers that might be present or missing\nThis is the most logical first step as it directly relates to the reported vulnerability and will help us understand the server's security posture.",
  "tool_calls": [
    {
      "id": "toolu_01SDWeJPzMZptuCBFmb7uRtA",
      "tool_name": "repeater",
      "arguments": {
        "request": "GET / HTTP/1.1\nHost: example.net\nAccept-Language: en-US,en;q=0.9\nUpgrade-Insecure-Requests: 1\nUser-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/136.0.0.0 Safari/537.36\nAccept: text/html,application/xhtml+xml,application/xml;q=0.9,image/avif,image/webp,image/apng,*/*;q=0.8,application/signed-exchange;v=b3;q=0.7\nSec-Ch-Ua: \"Not.A/Brand\";v=\"99\", \"Chromium\";v=\"136\"\nSec-Ch-Ua-Mobile: ?0\nSec-Ch-Ua-Platform: \"Windows\"\nSec-Fetch-Site: none\nSec-Fetch-Mode: navigate\nSec-Fetch-User: ?1\nSec-Fetch-Dest: document\nAccept-Encoding: gzip, deflate, br\nPriority: u=0, i\nConnection: keep-alive",
        "learnings": "This is the first step, so there are no previous learnings to evaluate. However, from the initial evidence, we can see that the application responds to HTTP requests without enforcing HTTPS, which confirms the reported vulnerability.",
        "progress": "This is the first step in our investigation. We'll start by examining the server's response headers to understand what security measures are in place and what might be missing.",
        "knowledge": "From the initial response, we can see that the server supports HTTP/2 and offers alternative services including h3 (HTTP/3) and QUIC on port 443. The server appears to be a standard web server serving static content.",
        "step_title": "Check for security headers and HTTPS redirect",
        "step_action": "I'm sending a basic GET request to examine the server's security headers and see if there's any HTTPS redirect mechanism in place. This will help us understand what security controls are missing and how we might exploit this weakness. Specifically, I'm looking for:\n1. Absence of HSTS header\n2. Lack of automatic HTTPS redirect\n3. Any other security headers that might be present or missing\nThis is the most logical first step as it directly relates to the reported vulnerability and will help us understand the server's security posture."
      }
    }
  ]
}

Next /continue request: includes the prior response, same GUID, adds X-Forwarded-Proto: http.

'Explore HSTS' request #2

POST /ai/hakawai-explore-service/api/v1/continue HTTP/2
Host: ai.portswigger.net

{
  "exploration_id": "{{ same guid as before }}",
  "tool_results": [
    {
      "tool_id": "toolu_01SDWeJPzMZptuCBFmb7uRtA",
      "result": "{{ response }}"
    }
  ]
}

The response adds a description and the next action (send another request).

'Explore HSTS' response #2

Structure:

{
    "exploration_id": "{{ same guid as before }}",
    "step_title": "Test proxy header behavior",
    "step_action": "From the previous response, we confirmed that the server:\n1. Lacks HSTS headers\n2. Doesn't force HTTPS redirects\n3. Has minimal security headers\n4. Serves content over HTTP/2 despite being accessed via HTTP\n\nI'm adding the X-Forwarded-Proto header set to 'http' to see if the server's behavior changes when it believes the request came through a proxy. This could reveal if there's any proxy-aware security logic that might help us understand how the server handles SSL/TLS decisions. This is important because many applications implement HTTPS enforcement at the proxy level, and understanding this behavior could reveal additional attack vectors.",
    "tool_calls": [
        {
            "id": "toolu_01JRsZBtYYhoUsrYXasMkWTY",
            "tool_name": "repeater",
            "arguments": {
                "request": "{{ request}}",
                "learnings": "From the previous response, we confirmed that the server:\n1. Lacks HSTS headers\n2. Doesn't force HTTPS redirects\n3. Has minimal security headers\n4. Serves content over HTTP/2 despite being accessed via HTTP",
                "progress": "We're making progress in understanding the server's security configuration. Now we'll test if the server behaves differently when it thinks the request came through a proxy, which could reveal additional vectors for exploitation.",
                "knowledge": "The server is running a modern stack with HTTP/2 and HTTP/3 support, but lacks basic security headers. It also appears to be a static content server with no obvious signs of a complex application stack.",
                "step_title": "Test proxy header behavior",
                "step_action": "I'm adding the X-Forwarded-Proto header set to 'http' to see if the server's behavior changes when it believes the request came through a proxy. This could reveal if there's any proxy-aware security logic that might help us understand how the server handles SSL/TLS decisions. This is important because many applications implement HTTPS enforcement at the proxy level, and understanding this behavior could reveal additional attack vectors."
            }
        }
    ]
}

Final /continue contains the previous response.

POST /ai/hakawai-explore-service/api/v1/continue HTTP/2
Host: ai.portswigger.net


{
  "exploration_id": "{{ same guid as before }}",
  "tool_results": [
    {
      "tool_id": "toolu_01JRsZBtYYhoUsrYXasMkWTY",
      "result": "{{ response }}"
    }
  ]
}

That response ends the conversation.

'Explore HSTS' response #3

If you want to copy the structure:

{
  "exploration_id": "{{ same guid as before }}",
  "step_title": "Report findings on HTTPS enforcement vulnerability",
  "step_action": "The server consistently serves content over HTTP without any security redirects or headers, regardless of the protocol or proxy headers used. This behavior persists even when explicitly indicating HTTP traffic through proxy headers.\n\nAfter confirming the lack of HTTPS enforcement through multiple test cases, including direct requests and proxy-aware testing, it's appropriate to report our findings. The vulnerability has been fully verified and its impact understood, making this the logical conclusion to our testing.",
  "tool_calls": [
    {
      "id": "toolu_01FUxXnvkaDVNNK6NYDkMikj",
      "tool_name": "reporter",
      "arguments": {
        "report": "We have confirmed that the server accepts HTTP traffic without enforcing HTTPS, lacks HSTS headers, and does not implement any form of SSL/TLS redirect mechanism, even when accessed through a proxy. This vulnerability allows an attacker to perform SSL stripping attacks, potentially intercepting all traffic between users and the server, including any sensitive data or authentication credentials that may be transmitted.",
        "learnings": "The server consistently serves content over HTTP without any security redirects or headers, regardless of the protocol or proxy headers used. This behavior persists even when explicitly indicating HTTP traffic through proxy headers.",
        "progress": "We have thoroughly tested the server's behavior regarding HTTPS enforcement and confirmed the vulnerability. Further testing would not reveal additional information about this specific issue.",
        "knowledge": "The server runs a modern stack with HTTP/2 and HTTP/3 support (on port 443) but lacks fundamental security headers and HTTPS enforcement. It appears to be primarily serving static content.",
        "step_title": "Report findings on HTTPS enforcement vulnerability",
        "step_action": "After confirming the lack of HTTPS enforcement through multiple test cases, including direct requests and proxy-aware testing, it's appropriate to report our findings. The vulnerability has been fully verified and its impact understood, making this the logical conclusion to our testing."
      }
    }
  ]
}

Task view shows the summary, results, and the request/responses.

'Explore HSTS' task summary

In Repeater (and elsewhere) highlight text and right‑click. Select Explain This (top of the context menu). Here I highlighted the full request to example.net.

'Explain This' button

This results in a POST request to https://ai.portswigger.net/ai/hakawai-explain-this/api/v1/explainthis.

'Explain This' request #1

POST /ai/hakawai-explain-this/api/v1/explainthis HTTP/2
Host: ai.portswigger.net

{
  "text": "{{ request }}",
  "context": "REQUEST_HEADERS"
}

Note the context. When I changed this request to POST and added some dummy values, the value of context changed to REQUEST.

The response just explains the issue.

'Explain This' response

Response structure:

{
  "content": "{{ removed }}"
}

And this appears in the sidebar.

'Explain This' results in the side bar

When scanning APIs Burp can record a login sequence with AI. Here I use Google's Gruyere, an intentionally vulnerable app.

First I created an instance and account gru_user:gru_password. Instance URL is https://google-gruyere.appspot.com/[numbers]/. Then I started a scan and chose AI recorded login.

Recording a new login with AI

Supply URL, username, and password. I could speed it up by starting at the login page, but I wanted to see the discovery process.

Info for AI recorded login

In the first step, Burp sends the following information to https://ai.portswigger.net/ai/hakawai-recorded-login-generator/api/v1/start in a POST request:

URL
Title
Page text
An array of elements (links, inputs, buttons, etc.)
A screenshot of the page in base64

POST /ai/hakawai-recorded-login-generator/api/v1/start HTTP/2
Host: ai.portswigger.net

{
  "page_description": {
    "url": "https://google-gruyere.appspot.com/{{ gruyere-instance-id }}/",
    "title": "Gruyere: Home",
    "text": "Home Sign in | Sign up Gruyere: [removed]",
    "interactive_elements": [
      {
        "id": 15,
        "text": "Home",
        "attributes": "href=/{{ gruyere-instance-id }}/",
        "input_value": null,
        "accepts_input": false
      },
      {
        "id": 18,
        "text": "Sign in",
        "attributes": "href=/{{ gruyere-instance-id }}/login",
        "input_value": null,
        "accepts_input": false
      }, // removed the rest
    ],
  }
}

The response tells the recorder to click Sign in:

{
  "recorded_login_id": "{{ guid }}",
  "tool_call": {
    "id": "toolu_01KLBGYsdH6JBvrcf6ircZkx",
    "tool_name": "click_element",
    "arguments": {
      "id": 18,
      "reason": "Clicking the \"Sign in\" link to navigate to the login page since we need to log in with existing credentials"
    }
  }
}

We've reached the login page. The next request has similar info about this page.

POST /ai/hakawai-recorded-login-generator/api/v1/continue HTTP/2
Host: ai.portswigger.net

{
  "recorded_login_id": "{{ same guid }}",
  "tool_result": {
    "tool_id": "toolu_01KLBGYsdH6JBvrcf6ircZkx",
    "result": true
  },
  "page_description": {
    "url": "https://google-gruyere.appspot.com/{{ gruyere-instance-id }}/login",
    "title": "Gruyere: Login",
    "text": "Home Sign in | Sign up Gruyere: Login User name: Password: Login",
    "interactive_elements": [
      // removed
      {
        "id": 160,
        "text": "",
        "attributes": "type=password",
        "input_value": "",
        "accepts_input": true
      },
      {
        "id": 165,
        "text": "Login",
        "attributes": "type=submit",
        "input_value": "Login",
        "accepts_input": true
      }
    ],
  }
}

Username and password are never sent to AI (another point to PortSwigger). The response from AI tells the recorder to enter the username.

{
  "recorded_login_id": "{{ same guid }}",
  "tool_call": {
    "id": "toolu_018auKHege7thfnHrVQSsb2f",
    "tool_name": "input_text",
    "arguments": {
      "id": 154,
      "text": "USERNAME_PLACEHOLDER",
      "reason": "Entering username in the username field"
    }
  }
}

After that, this request goes out.

POST /ai/hakawai-recorded-login-generator/api/v1/continue HTTP/2
Host: ai.portswigger.net

{
  "recorded_login_id": "b416611a-16d5-492d-8a4f-7826774dfec3",
  "tool_result": {
    "tool_id": "toolu_018auKHege7thfnHrVQSsb2f",
    "result": true
  },
  "page_description": {
    "url": "https://google-gruyere.appspot.com/{{ gruyere-instance-id }}/login",
    "title": "Gruyere: Login",
    "text": "Home Sign in | Sign up Gruyere: Login User name: USERNAME_PLACEHOLDER Password: Login",
    "interactive_elements": [
      // removed
      {
        "id": 154,
        "text": "USERNAME_PLACEHOLDER",
        "attributes": "type=text",
        "input_value": "USERNAME_PLACEHOLDER",
        "accepts_input": true
      },
      {
        "id": 160,
        "text": "",
        "attributes": "type=password",
        "input_value": "",
        "accepts_input": true
      },
      {
        "id": 165,
        "text": "Login",
        "attributes": "type=submit",
        "input_value": "Login",
        "accepts_input": true
      }
    ],
  }
}

AI tells Burp to enter the password.

{
  "recorded_login_id": "{{ same guid }}",
  "tool_call": {
    "id": "tooluse_DDIbQfI0TiGlRbSCTIw67g",
    "tool_name": "input_text",
    "arguments": {
      "reason": "Entering password in the password field",
      "id": 160,
      "text": "PASSWORD_PLACEHOLDER"
    }
  }
}

Next request shows the entered password.

POST /ai/hakawai-recorded-login-generator/api/v1/continue HTTP/2
Host: ai.portswigger.net

{
  "recorded_login_id": "b416611a-16d5-492d-8a4f-7826774dfec3",
  "tool_result": {
    "tool_id": "tooluse_DDIbQfI0TiGlRbSCTIw67g",
    "result": true
  },
  "page_description": {
    "url": "https://google-gruyere.appspot.com/{{ gruyere-instance-id }}/login",
    "title": "Gruyere: Login",
    "text": "Home Sign in | Sign up Gruyere: Login User name: USERNAME_PLACEHOLDER Password: •••••••••••• Login",
    "interactive_elements": [
      // removed
      {
        "id": 154,
        "text": "USERNAME_PLACEHOLDER",
        "attributes": "type=text",
        "input_value": "USERNAME_PLACEHOLDER",
        "accepts_input": true
      },
      {
        "id": 160,
        "text": "••••••••••••",
        "attributes": "type=password",
        "input_value": "PASSWORD_PLACEHOLDER",
        "accepts_input": true
      },
      {
        "id": 165,
        "text": "Login",
        "attributes": "type=submit",
        "input_value": "Login",
        "accepts_input": true
      }
    ],
  }
}

Then AI tells Burp to click the login button.

{
  "recorded_login_id": "b416611a-16d5-492d-8a4f-7826774dfec3",
  "tool_call": {
    "id": "toolu_015P9EuahD1iuQR3ETzyU1q4",
    "tool_name": "click_element",
    "arguments": {
      "id": 165,
      "reason": "Clicking the Login button to submit the login form now that both username and password have been entered"
    }
  }
}

After clicking login we reach the app and Burp reports back to AI.

{
  "recorded_login_id": "b416611a-16d5-492d-8a4f-7826774dfec3",
  "tool_result": {
    "tool_id": "toolu_015P9EuahD1iuQR3ETzyU1q4",
    "result": true
  },
  "page_description": {
    "url": "https://google-gruyere.appspot.com/{{ gruyere-instance-id }}/login?uid=gru_user&pw=gru_password",
    "title": "Gruyere: Home",
    "text": "Home | My Snippets | New Snippet | Upload USERNAME_PLACEHOLDER <USERNAME_PLACEHOLDER> | Profile | Sign out Gruyere: Home Refresh Most recent snippets: Cheddar Mac Gruyere is the cheesiest application on the web. All snippets  Homepage Brie Brie is the queen of the cheeses!!! All snippets  Homepage",
    "interactive_elements": [
      // removed the elements on the page
      {
        "id": 230,
        "text": "Sign out",
        "attributes": "href=/{{ gruyere-instance-id }}/logout",
        "input_value": null,
        "accepts_input": false
      },
    ],
  }
}

For some reason, AI never sends a response here and Burp cannot complete the login sequence. I tried multiple times and it always stops here.

Video capture below. I trimmed ~15 seconds between steps.

What is This Useful For?

You can build an extension to run on the 2nd instance (Burp server) and redirect AI traffic to your endpoint. Recreate the prompts (they're obvious) and ensure the responses are in the correct JSON format. Then you can run Burp AI flows with your own local or remote AI instance.

Extension developers can create a simple wrapper for AI calls and let users choose a custom instance or Burp AI. I vibecoded a helper library for this in ~15 minutes.

Suggestion to PortSwigger

Let users configure the AI endpoint and include the prompts. The OpenAI API (e.g., chat/completions) is the de facto standard so it should not require a lot of customization. You're not in the business of selling AI compute :)

Hackerman's Hacking Tutorials

The knowledge of anything, since all things have causes, is not acquired or complete unless it is known by its causes. - Avicenna

How Burp AI Works

Quick Start

Quick Facts

Motivation

Proxying Burp

Checking the Logs

Upstream Proxy

JRE cacerts File

What's Inside Burp AI

Explore Issue

'Explain This' Context Menu Item

What is This Useful For?

Suggestion to PortSwigger

Other Solutions

Other Java Proxy Settings

Hooking

Quick Start

Quick Facts

Motivation

Proxying Burp

Checking the Logs

Upstream Proxy

JRE cacerts File

What's Inside Burp AI

Explore Issue

'Explain This' Context Menu Item

AI Recorded Login

What is This Useful For?

Suggestion to PortSwigger

Other Solutions

Other Java Proxy Settings

Hooking
